| Door Thickness | 40-120mm |
| Material | Aluminum alloy (Front/ Rear Panel) |
| Lock cylinder | C-level lock cylinder (Brass) |
| Power Supply | DC 7.4V (Rechargeable Lithium battery, recommended capacity ≥4200mAh) |
| Low Voltage Warning | <6.9V |
| Backup Power | 5V (USB) |
| Standby Current | 130μA (in deep sleep mode) |
| Operating Current | <2A (average) |
| Network | 2.4G WiFi |
| Keypad | 13-key capacitive touch (0-9, *#, Lock) |
| Keypad Backlight | White LED |
| Front Display | 0.96 OLED (white) |
| Front Speaker | 8Ω, 1W |
| Rear Speaker | 8Ω, 1W |
| Max User Capacity | 250 (Face + Palm Vein + Fingerprint + PIN + Card) |
| Administrators | 10 (Fingerprint + PIN + Card) |
| Users | 240 (Face + Palm Vein + Fingerprint + PIN + Card) |
| Face + Palm Vein Capacity | 50 |
| Fingerprint Capacity | 100 |
| Fingerprint Type | Semiconductor fingerprint sensor |
| Card Type | High-frequency Mifare card / Mobile NFC card |
| Card Detection Range | 0-40mm |
| Human Detection | Radar sensor |
| Detection Range | Adjustable (approx. 0.8m~1.5m, depends on installation) |
| Face Recognition Type | 3D |
| Face Recognition Range | Vertical angle ≤15° (height coverage: 1.2m~2.0m) |
| FAR | <0.001% |
| FRR | <2% |
| Operating Temperature | -20℃ ~ 60℃ |
| Operating Humidity | 10% ~ 90% (non-condensing) |
| Storage Temperature | -30℃ ~ 70℃ |
| ESD Protection | Contact discharge: ±8kV, Air discharge: ±15kV |
